SQ RANGE

For quarter-turn valves, BERNARD CONTROLS' SQ weatherproof range features heavy duty mechanical design and increased reliability, security and user-friendliness for INTEGRATED & INTELLI+® control versions.

SWITCH MODEL

INTELLI MODEL

HIGH TORQUE VERSION

PRODUCT SPECIFICATIONS

TORQUE RANGE

· 45 to 10,000 Nm (up to 800 Nm direct mount)

· Up to 1,000,000 Nm on request

TYPE OF CONTROLS:

· Electromechanical SWITCH

· Integrated INTEGRAL

· Integrated INTELLI+®(v2)

BC DUTY & MODULATING CLASSIFICATION:

· On-Off: Class A +

· Inching / Positioning: Class B+

· Modulating: Class III

CONNECTOR: DOUBLE-SEALING WITH INTELLI+®

ENVIRONMENT: IP 68 / C3 UP TO C5-M

T: -20°C ...+70°C option low T° -40°C on all models and option high T° +90°C for SWITCH versions only

PRODUCT BENEFITS

INDUSTRIAL GRADE ACTUATORS

BERNARD CONTROLS has achieved an excellent reputation over the years in the Power, Water & Industry markets thanks to a range of actuators providing the following features:

· Compact construction with a high output torque

· Self-locking gear train to maintain the position of the valve when the actuator is de-energized

· Very good resistance to vibrations

· Very simple settings - no specific tool required

· Adjustable mechanical travel limit stops to prevent overtravel Removable drive socket for easy machining

· Emergency handwheel and mechanical position indicator provided on all actuators as a standard
